品牌：SunKun(三昆)

型號：SK-108-650

訂購：不限數量

價格：面議

⒈訂購熱線：13823369867(李先生) 1753480168

⒉業務咨詢：13913507139(黃永貴) 2851085006



⒈市場部：13510246266(黃總經理) 289604232

1、UV燈功率:8.0kw*1支(UV燈)
2、UV燈總長:780mm、弧長:680mm
3、UV波段主波峰:365nm
4、UV燈累時器單獨配置
5、強弱光強調節:20%~100%(無級調節)
6、鈑金燈箱安裝進口插片反射器
7、燈箱升降采用手輪調節
8、采用上排風系統
9、輸送材料:特氟龍網帶(加導條)
10、輸送寬度:650mm
11、輸送速度:1~10m/min
12、入口高度:100mm
13、電源:380VAC50HZ

Technical Parameters:
1, UV lamp power: 8.0kw * 1 (UV lamp)
2, the total length of the UV lamp: 780mm, arc length: 680mm
3, UV band main peak: 365nm
4, UV lamp chronograph is configured separately
5, strong and weak light intensity adjustment: 20% ~ 100% (stepless adjustment)
6, sheet metal light box installation of imported insert reflector
7, the light box lift uses handwheel adjustment
8, using the upper exhaust system
9, conveying materials: Teflon mesh belt (plus guide bars)
10, conveying width: 650mm
11, conveying speed: 1~10m/min
12, the entrance height: 100mm
13, power: 380VAC50HZ

適用范圍：
各種UV涂料、IMD注塑產品油墨固化；用于在固化電子元件、液晶片、端子膠封、手機組件粘合、塑膠組件粘合及LCD等；該裝置體積小，重量輕，制作精良，移動方便。

性能特點：
·瞬間干燥，節省時間，生產效率高；　
·能使印件表面達到高光澤，耐磨擦、耐溶劑的效果；　
·進口鐵氟龍網帶，輸送速度平衡可調，可方便的與生產線及其它設備聯接；　
·每套UV系統獨立控制，依生產開啟燈管數量；　
·采用特殊的鋁鎂合金燈罩，聚光型設計，生產效率高；　
·UV燈管的工作電流可通過外示表針控制，有效掌握UV系統的工作狀態；　
·配備合理的散熱系統，防止工作腔室的溫度過高導致紙張變形；熱量通過排熱系統可排出室外，同時有效保護生產工作環境

Scope of application:
Various UV coatings, IMD injection molding products, ink curing; used in curing electronic components, liquid crystal films, terminal seals, mobile phone component bonding, plastic component bonding, LCD, etc.; the device is small, lightweight, well-made, mobile Convenience.
